Developing Arrow C++ Compute#
This section provides information for developers of the Arrow C++ Compute module.
Row Table#
The row table in Arrow represents data stored in row-major format. This format is particularly useful for scenarios involving random access to individual rows and where all columns are frequently accessed together. It is especially advantageous for hash-table keys and facilitates efficient operations such as grouping and hash joins by optimizing memory access patterns and data locality.
Metadata#
A row table is defined by its metadata, RowTableMetadata, which includes
information about its schema, alignment, and derived properties.
The schema specifies the types and order of columns. Each row in the row table contains the data for each column in that logical order (the physical order may vary; see Row Encoding for details).
One important property derived from the schema is wether the row table is fixed-length or varying-length. A fixed-length row table contains only fixed-length columns, while a varying-length row table includes at least one varying-length column. This distinction determines how data is stored and accessed in the row table.
Each row in the row table is aligned to RowTableMetadata::row_alignment
bytes. Fixed-length columns with non-power-of-2 lengths are also aligned to
RowTableMetadata::row_alignment bytes. Varying-length columns are aligned to
RowTableMetadata::string_alignment bytes.
Buffer Layout#
Similar to most Arrow Arrays, the row table consists of three buffers:
Null Masks Buffer: Indicates null values for each column in each row.
Fixed-length Buffer: Stores row data for fixed-length tables or offsets to varying-length data for varying-length tables.
Varying-length Buffer (Optional): Contains row data for varying-length tables; unused for fixed-length tables.
Row Format#
Null Masks#
For each row, a contiguous sequence of bits represents whether each column in
that row is null. Each bit corresponds to a specific column, with 1
indicating the value is null and 0 indicating the value is valid. Note that
this is the opposite of how the validity bitmap works for Arrays. The null
mask for a row occupies RowTableMetadata::null_masks_bytes_per_row bytes.
Fixed-length Row Data#
In a fixed-length row table, row data is directly stored in the fixed-length
buffer. All columns in each row are stored sequentially. Notably, a boolean
column is special because, in a normal Arrow Array, it is stored using 1
bit, whereas in a row table, it occupies 1 byte. The varying-length buffer is
not used in this case.
For example, a row table with the schema (int32, boolean) and rows
[[7, false], [8, true], [9, false], ...] is stored in the fixed-length
buffer as follows:
Row 0 |
Row 1 |
Row 2 |
… |
|---|---|---|---|
|
|
|
… |
Offsets for Varying-length Row Data#
In a varying-length row table, the fixed-length buffer contains offsets to the
varying-length row data, which is stored separately in the optional
varying-length buffer. The offsets are of type RowTableMetadata::offset_type
(fixed as int64_t) and indicate the starting position of the row data for
each row.
Varying-length Row Data#
In a varying-length row table, the varying-length buffer contains the actual row data, stored contiguously. The offsets in the fixed-length buffer point to the starting position of each row’s data.
Row Encoding#
A varying-length row is encoded as follows:
Fixed-length columns are stored first.
A sequence of offsets to each varying-length column follows. Each offset is 32-bit and indicates the end position within the row data of the corresponding varying-length column.
Varying-length columns are stored last.
For example, a row table with the schema (int32, string, string, int32) and
rows [[7, 'Alice', 'x', 0], [8, 'Bob', 'y', 1], [9, 'Charlotte', 'z', 2], ...]
is stored as follows (assuming 8-byte alignment for varying-length columns):
Fixed-length buffer (row offsets):
Row 0 |
Row 1 |
Row 2 |
Row 3 |
… |
|---|---|---|---|---|
|
|
|
|
… |
Varying-length buffer (row data):
Row |
Fixed-length Cols |
Varying-length Offsets |
Varying-length Cols |
|---|---|---|---|
0 |
|
|
|
1 |
|
|
|
2 |
|
|
|
3 |
… |
… |
… |
